Premium Automatic Batter Cage For Laying Chickens In Africa Market
Chicken Cage Iris
Automatic layer cage system suitable big farm over 15000 birds , it
is full automatic
keep period: from 12 weeks to adult.
Anti-corrosion treatment process: Electrostatic spraying,
Aluminum-zinc alloy, Hot-dip galvanized
Service time: over 25 years lifespan
Egg breaking rate: ≤0.5%
1. Specification
| BEST A type automatic laying chicken cage system |
| Model | Tier | Capacity | Total nests(doors) | Cage size(L*W*H) |
| A-120 | 3 | 120 birds | 30 nests(doors) | 2.2m*2.4m*1.65m |
| A-160 | 4 | 160 birds | 40 nests(doors) | 2.2m*2.4m*1.95m |
| Material | Q-235 low carbon steel wire/galvanized wire/coated wire |
| Service lifespan | Hot deep galvanized cage with over 25 years lifespan. Notes: The service life depends on the surrounding environment |
2. Details of chicken cage accessories
Automatic cage system : cage mesh, cage frame. Automatic drinking
system,automatic feeding system, automatic egg collection system,
automatic manure cleaning system
Hot deep galvanized with over 25 years lifespan
Automatic drinking system
Water Pressure: Better water pressure regulation
Nipple drinker is made of stainless steel, which can effectively
prevent rust and water leakage
The drinking system adopt the closed piping system, which can
minimize the water pollution
Automatic Feeding System is connected with the augers which be
delivered the feed from silo to the hopper and then can transfer
the feed to feed troughs
The feeding process all the use of automated control, it can adjust
the amount of materials. Prevents the waste of feed
Automatic egg collection system
The bottom of the cage mesh extends outwards. After the chicken
lays eggs, it will drop directly to the bottom mesh. There is an
egg belt on the bottom mesh,when the machine switch is turned on,
the egg belt will run automatically and transfer the eggs to the
egg collection machine, reduce egg breakage
Automatic manure cleaning system
Manure scrapper machine, It is installed in the manure pit under
the cage, for A type cages, the chicken manure will drop into
manure pit directly,when the machine switch is turned on, the
scraper will operate to collect the chicken manure in the chicken
house, Fast and efficient, reduce bad smell,keep the chicken shed
dry and clean
3. Advantage
1) Labor saving and time saving
2) Reduce waste
3) Low egg breaking rate
4) Simple structure, convenient operation and maintenance, high
selectivity of automation equipment, low input cost, fast harvest
5) High quality,hot deep galvanized with over 25 years lifespan.
4. Service
1) Free house layout
According to your land size and shape, design easy management and
high effective farm project
2) Premium installation service
We will send our technicians to your farm to guide the installation
for you
3) Visit our china factory
We welcome you to visit our factory at any time, your suggestion is
our driving force
5. Why choose us?
1) Hebei Best Machinery And Equipment Co., Ltd.,found in 1996,
360KM from BEIJING city, from raw materials to finished products,
strict implementation of ISO 9001:2008 quality management system
2) We also set up warehouse and factory in Lagos, Nigeria from 2008
till now.
3) We have advanced technical equipment,we can also provide
installation and technical guidance
4) Good service and complete after-sales service system
5) Products have been exported to many countries, such as
Australia, Cameroon, Grenada, Ghana, Gambia, Guyana, Honduras,
Haiti, Hungary, India, Kenya, Sir Lanka, Tanzania, Uganda, United
Kingdom, South Africa, Zambia, Zimbabwe,etc
6. Poultry farm one-stop shopping
We are the manufacturer of chicken cage and poultry equipment. You
could get one-stop services,we provide you with complete raising
solutions
For broilers: broiler cage, manual drinker and manual feeder,
heater machine, automatic drinking and feeding line, chicken
plucker machine, chicken cutter machine, cold room and so on
For chicks: egg incubator machine, chicks cage, automatic bell
drinker, automatic drinking and feeding line
For layers: layer cage, automatic layer cage system
For chicken feeds: feed mill machine, trolley feeding machine
For chicken waste: manure scrapper machine, manure dryer machine
For more details, welcome contact us.
