Automatic Brooder Chicken Cage System For Pullet Chicks Sandy
Introduction of automatic brooder chicken cage
1. It is used to keep chicks from one day to 12 or 16 weeks old,
after that, farmers will transport them to egg laying chicken cage
also named layer cage, finish the whole rearing processing
2. It helps the farmers to get best rearing effect because of all
chicken rearing period will be controlled by automatic system with
high automation
3. Automatic drinking, feeding, manure removal system
The specification of pullet chicken cage
| Product name | Automatic brooder chicken cage |
| Application | Chicken poultry farm rearing |
| Usage | For day old chicks |
| Material | Hot galvanization |
| Capacity | 120 Birds or customization |
| Drinking system | Nipple drinker and manual drinker |
| Feeding system | Feeding trough and manual feeder |
| Local service | Nigeria, China factory whole year stocks |
| Service | Supply installation tools, video, local professional team |
| Key words | Full automatic system |
Introduction of automatic pullet cage
Cage system
1. Automatic drinking system, water pipe height can be adjusted
according to the growing size of the birds
2. The cage mesh surface is hot deep galvanized, which can keep
long lifespan, better elasticity and higher intensity
3. There are feeding holes couples with the feed troughs for
starting rearing period, and the holes’ height can be adjusted to
higher level with the pullets growing, very easy to operate
Automatic feeding system
In this system, feed is distributed automatically to the feed carts
from the feed silos by the spiral augers located in a pipe with
90-150mm diameter
1) Fittings is motor, hopper, hopper frame with tracking and
assistant fittings
2) Automatic working for 1 row/set
3) Power is 1.5kw and voltage 380v
4) Reduce labour cost, finish feeding automatically
5) Stainless steel material, longer lifespan
Automatic manure cleaning system
1. Scraper Type
The scraper type is suitable for A type cages, which can clean two
or three rows. It can not only save some labor cost, but also save
some investment in the whole project.
The cleaning speed is 6-10 meters per minute
2. Conveyor Belt Type
1) Suitable for both A type cages and H type cages, which can
reduce the labor intensity and labor cost, keep the chicken shed
dry and clean. Each row needs a set of manure removing machine.
2) Manure removing belt we use is 1.1 mm, PP material
(polypropylene), corrosion-resistant and antibacterial
3) Manure Clean system is designed with pressure rollers and rubber
rollers, which reduces the problem of motor idling and deviation.
It can be used for a long time without adjusting the belt
The walking speed is 2-4 meters per minute
